Authenticate to Microsoft Fabric ​

There are two ways to authenticate: with the Microsoft Authenticator node, or with a KNIME Hub secret via the Secrets Retriever node. Both options produce a credential that connects to a Fabric workspace.

Option 1: Microsoft Authenticator node ​

The Microsoft Authenticator node authenticates to Microsoft Azure services, including Microsoft Fabric. It supports two authentication types: interactive and Application/Service principal.

Workflow showing authentication flow using the Microsoft Authenticator node

Interactive authentication ​

Use interactive authentication for manual workflow runs where a human is present and browser login is available.

  1. Configure the Microsoft Authenticator node: set Authentication type to Interactive.
  2. Leave the scope empty.
  3. In the node configuration, click Login.

Microsoft Authenticator node dialog with Interactive authentication type selected

WARNING

Interactive authentication does not work for scheduled workflows on KNIME Hub because no human is present to complete the browser login. Use Application/Service principal authentication or a KNIME Hub secret instead.

Application/Service principal authentication ​

Use this option for scheduled or automated workflows where no user is present.

  1. Configure the Microsoft Authenticator node: set Authentication type to Application/Service principal.
  2. Enter the Azure tenant ID or domain.
  3. Enter the Azure application ID and secret value.
  4. Leave the scope empty.

As you connect and execute downstream nodes, the Microsoft Authenticator node automatically fetches the required scopes — https://api.fabric.microsoft.com/.default for the Fabric Workspace Connector, https://database.windows.net/.default for the Data Warehouse Connector, and https://storage.azure.com/.default for the OneLake Connector.

Option 2: KNIME Hub secret ​

Use the Secrets Retriever node to retrieve a Microsoft secret from the KNIME Hub secret store. This option is well-suited for scheduled workflows — no user interaction is required at runtime. To set up the secret, see Create a secret on KNIME Hub.

Workflow showing authentication flow using a KNIME Hub secret and Secrets Retriever node

The Secrets Retriever node outputs a credential port you connect directly to the Microsoft Fabric Workspace Connector node. For details on retrieving and using secrets, see Use secrets in a workflow.

Use a secret for DB Loader staging storage ​

The DB Loader node writes to a Fabric Data Warehouse through a staging area in Azure Blob Storage or Azure Data Lake Storage Gen2. To authenticate the storage connector with a KNIME Hub secret, create a separate Microsoft secret with a custom scope for your storage account:

  • Scope request mode: During login
  • Scope type: Custom
  • Scopes of access: https://NaN.blob.core.windows.net/.default

Replace NaN with the name of your Azure storage account. Assign the identity behind the secret a data access role on the storage account. For details, see Azure RBAC for Blob data. Connect this secret to the storage connector, and connect the Fabric secret to the Microsoft Fabric Workspace Connector node. For the DB Loader configuration, see Load data.

Connect to a workspace ​

Regardless of which authentication option you chose, the next step is connecting to a Fabric workspace. The Microsoft Fabric Workspace Connector node takes the credential output and establishes the connection.

  1. Connect the output of the Microsoft Authenticator node or the Secrets Retriever node to the Microsoft Fabric Workspace Connector node.
  2. If your account has access to multiple workspaces, select one in the node configuration.
  3. Execute the node.

The output is a Microsoft Fabric Workspace Connection, required by:

  • Microsoft Fabric Data Warehouse Connector — for structured SQL operations
  • Microsoft OneLake Connector — for file-based data lake access
